October 21, 2024 – Jiangsu Pulimate New Material Co., Ltd. has recently made a significant breakthrough in the field of drying equipment technology, earning a patent from the National Intellectual Property Administration for “A Drying Device for Black Color Masterbatch,” with the authorization announcement number CN 221756567 U. This patent, dated back to February of this year, underscores the company’s relentless pursuit of technological innovation.
The novel patent primarily revolves around the drying process of black color masterbatch. The device boasts a sophisticated design, comprising a main body constructed with a drying tank and a base plate. The top of the drying tank is equipped with an upper cover and a conveniently placed feeding inlet, facilitating the addition of black color masterbatch. Most crucially, a heating coil is embedded within the inner wall of the drying tank, ensuring uniform heating of the black color masterbatch.
According to the Color Masterbatch Industry Network, to achieve even stirring and heating of the black color masterbatch, the device is equipped with an advanced drive system. A first motor is installed on the upper cover, with its drive end penetrating the interior of the drying tank and connecting to a connecting rod. This connecting rod is inclined on one side and fitted with a second motor. The drive end of the second motor fixes a rotating axis, which is equipped with multiple sets of stirring blades, at least three, ensuring thorough stirring of the black color masterbatch for uniform heating and preventing issues arising from uneven heat distribution.
Furthermore, the device features a discharge outlet at the bottom of the drying tank, facilitating the discharge of dried black color masterbatch. Additionally, a fixing ring is reinforced around the outer wall of the drying tank, not only enhancing the structural stability of the device but also effectively reducing noise and vibration, thereby preventing vibration wear and noise interference during operation.
The patent secured by Jiangsu Pulimate New Material Co., Ltd. undoubtedly offers a novel solution for the drying process of black color masterbatch, poised to significantly propel the further development of related industries.
